UHF Micro RFID Tag

The UHF Micro RFID Tag features a Alien Higgs 3 semiconductor and has achieved certification for Group I, II & III, ensuring comprehensive coverage for all your application needs. Elevate your Mining and Oil & Gas operations with the reliability and adaptability of this RFID Tag – where innovation meets safety

Electrical Specifications:

• Air Interface Protocol: ISO / IEC 18000-6C, EPC Global C1G2
• Operational Frequency: 865 – 868 MHz or 902 – 928 MHz
• Chip: Alien Higgs-3
• Memory Configuration:
  • EPC: 96 bits, extendible to 480 bits
  • TID: 96 bits unalterable unique
  • User memory: 512 bits
  • Access password: 32 bits
  • Kill password: 32 bits
• Product Code: U3211510
• Read Range: Up to 50mm
• Ingress Protection Rating: IP67 / IP68
• Attachment Methods: Riveting, Screw, Magnetic, Adhesive

Physical and Mechanical Specifications:

• Dimensions: 52 x 15 x 8.5 +/- 0.5 mm
• Weight: 5g
• Encasement: Polypropylene and Polycarbonate
• Colour: Grey
• Quality Assurance: 100% Reader Tested

Chemical Resistance:

• Resistant to continuous exposure to salt water for 2 hours
• Resistant to continuous exposure to motor oil for 2 hours
• Abrasion-resistant against HCL and IPA

Certificates:

• IECEx TSA 21.0010X
• Ex ia Ma
• Ex ia IIC T6 Ga
• Ex ia IIIC T135°C Da

Temperature Range:

• -20°C to 70°C

Additional Services:

• Pre-encoding available on request

PRICING FOR BULK BUYS

Generous discounts apply for bulk orders for 5,000 or more tags. Please click here to contact us for bulk order enquiries.
